FLD multi-layered sintered leaf filter disc
plate is made by the multi-layer sintered woven wire mesh through the special
stromatolithic pressing and vacuum sintering. It is a new filter media with
high mechanical strength and monolithic rigid structure. The sintered wire mesh
is easy to take shape, machine and welding.
The diffusion-boned wire cloth laminates
are made from layers of stainless steel wire cloth, which are furnace-sintered
together into seamless sheet. These porous metal structure provide accurate
filtration for greater strength and durability.
Sintered screens can be fastened by several
methods, for example, welding, caulking bars, threaded fasteners which are
welded to the downstream mesh layers. The screens are produced to precise size
to ensure the perfect fit.
The stainless steel filter elements are use
all over the world, designed for the filter edible oil and vegetable oil, for
instance, sunflower oil, rice brain oil, cottonseed oil, palm oil and sunflower
Features and Benefits
1.) High filtering efficiency;
2.) Complete enclosed filtration, no
leakage, no environmental pollution;
3.) Easy cleaning and repeated washing;
4.) Low equipment cost and running cost, it
is convenient to maintain equipment;
5.) The filter precision can reach the PPM
6.) Large filtration area and good dirt
7.) Excellent anti-acid, anti-alkahi, resist-temperature,
8.) Robust design;
9.) Bolted construction can be easily
10.) Long service time;
Filter Media Woven mesh or perforated mesh made of stainless steel 304, 304L,
316, 316L, 317L, 904L, & Monel Hastelloy etc.
Layers: 3 or 5 layers, or sintered.
Filter rate: 2um-300um;
1.) Edible oil industry;
2.) Beverage industry;
3.) Chemical industry;
4.) Pharmacy industry;
5.) Petrochemical industry;
7.) Vital oil distillation;
8.) Lube kind of oil re-refining;
1.) The sintered replacement basket filter and strainer is the filter core. The wire mesh belongs to the wear parts. It needs a special protection.
2.) After the filter has worked for some time, the impurities are removed in the filter core in time.
3.) When cleaning the impurities, the wire mesh should be care to ensure that the core is not deformed or damaged.
4.) Once the wire mesh is deformed or damaged, it should be replaced immediately.
The following parameter will be confirmed
2.) Work pressure;
3.) Operation pressure;
5.) Flange standard;
Later is always more expensive. Communication efficiency
and get our quickest reply. Your inquiry will be responded within 8 hours;
Our technical team help you convert
your ideas into visual design and it’s free; Free CDA design;
Samples: Free sample mockup is
provided for your confirmation before mass production;
Inspection: Strict quality
control ensure satisfied products be received in your hands;
Shipping arrangement: Buying
different items? Sent to us together to save more.
6.) ODM & EDM: design and
tailor-service for you based on your requirements;
1.) Warranty period is 12 months;
2.) Our technology team will support you
3.) Engineering service is available for
your machinery overseas
Frequently asked questions
1Q: Can you provide the detailed drawing?
Yes, we can provide the drawing after prepayment.
2Q: Are you a manufacturer or a trader?
We're a professional and experienced manufacturer located in Shandong Dezhou City.
3Q: Can you accept OEM?
Yes, we can produce the products based on your design and standard.
4Q: How about the delivery time?
Normally 15-25 working days after prepayment, we will make the delivery as soon as
